Center of Joint Usage „EHF radiospectroscopy”
(established in 2006 at O.Ya. Usikov Institute for Radiophysics and Electronics NAS of Ukraine)

Center18

Chief of CJU:
Head of Radiospectroscopy Dept. IRE NASU,
Prof., Dr. Sc.
TARAPOV Sergey
Please send your propositions and requests regarding the joint researches
either To:
Chief of CJU in IRE NASU
TARAPOV Sergey (Prof., Dr.Sci)
tel: +38-057-7634-363
fax: +38-057-3152-105
e-mail:tarapov@ire.kharkov.ua
or To:
Scientific Secretary of IRE NASU
POCHANINA Irina, (Ph.D.)
tel: +38-057-3150-011
fax: +38-057-3152-105
e-mail: pochanina@ire.kharkov.ua
Official Documents and Statute of Center of Joint usage see CJU Statute.pdf

CJU “EHF radiospectroscopy”

CJU „EHF radiospectroscopy” includes:

1. Vector Network Analyzer:

Vector Network Analyzer Agilent NA 5230A.

Parameters:

Frequency band – 50 MHz- 40 GHz

Maximum output power - +3 dBm

Dynamic range- 100 dB

Detailed description of options of NA 5230A can be find in Operating Manual (PNAHelp_487_7_Rus.chm)

Kits of associated elements for Vector Network Analyzer Agilent NA 5230A

1.1. Standard coaxial cables for frequency band 50 MHz- 40 GHz and the standard calibration kit.

1.2. Waveguide-coaxial adopters (performed in IRE NASU) for waveguides of metric standard for the following frequency bands:

1.2.1.=8 mm (f=32-40 GHz);  -7.2 mm 3.6 mm;

1.2.2.=10 mm (f=16-26 GHz);   -11 mm 5.5 mm;

1.2.3.=30 mm (f=8-15 GHz);    -23 mm 10 mm;

1.3. Coaxial-coaxial adopters Coaxial-coaxial adopters:

1.3.1. standard "Pastenak" (Agilent ), 2.4 mm - standard "Pishta"

1.3.2. standard "Pastenak" (Agilent ) 2.4 mm - standard "SMA"

1.3. Kit of waveguide elements of metric standard (8 mm è 30 mm bands)

2. Radiospectroscopy experimental units/complexes

for the researches with usage of methods of magnetic and non-magnetic EHF-spectroscopy in the frequency band 10 GHz-150 GHz; temperature diapason 0.3 K-300 K and at static magnetic fields up to 7.5 T.

Detailed information is presented in web-sites of IRE NASU:

(http://www.ire.kharkov.ua/Radiospectroscopy/index.htm, http://www.ire.kharkov.ua)

Vector Network Analyzer Agilent NA 5230A application

Vector Network Analyzer Agilent NA 5230A application


Vector Network Analyzer Agilent NA 5230A with module for measuring the parameters of open resonant structures.

image014Waveguide-coaxial and Coaxial-coaxial adopters (10-40 GHz band) for Vector Network Analyzer Agilent NA 5230A, manufactured in IRE NAS of Ukrain


Vector Network Analyzer Agilent NA 5230A with module for investigation of magnetoimpedance in nanostructures

Main Parameters of Vector Network Analyzer Agilent NA 5230A

Main Parameters of Vector Network Analyzer Agilent NA 5230A. We can send the Operating Manual for your request
