IPR Structure

The main concept of the passive imaging system with multi-beam rotating diffraction type antenna is based on the two initial inventions generated in the IRE NASU at during 2001-2008. These inventions were initially patented in Ukraine with IRE NASU as the owner, but international patents were not secured those time. In 2010 with starting STCU P389 project these inventions were proposed for international patenting with applicant other than IRE NASU and patents for inventions were secured at different countries. Now the structure of IP rights for these inventions is the next:

A) Patents for invention in Ukraine:

Shylo S., Komyak V., Patent (UA) UA56347, G01S13/95, Multi-beam scanning ultra-high frequency radiometer, application 2001042485 13.04.2001, patent date 15.05.2003, bulletin 5 (2003).

Shylo S., Sydorenko Yu. Patent (UA) UA85932, G01S13/95, A method of radiometric images formation and antenna for realization of thereof, application a200706892 19.06.2007, patent date 10.03.2009, bulletin 5 (2009).

These patents are still actual this time at the territory of Ukraine.

B)  Patents for invention outside territory of Ukraine:

Shylo S., Sydorenko Yu. Patents (USA) US8836598 + US9105960 + US9385426, A method for formation of radiometric images and an antenna for implementation of the method, applications US2011298680, US2014347236, US2015320322.

Shylo S., Sydorenko Yu. Patent (China) CN102439403, A method for formation of radiometric images and an antenna for implementation of the method.

Shylo S., Sydorenko Yu. Patent (EU) ES2662892, A method for formation of radiometric images and an antenna for implementation of the method.

Mentioned above national patents are actual at the territory of appropriate countries.

The invention also was passed trough international expertise as: Shylo S., Sydorenko Yu. Patent WO2010/070257, A method for formation of radiometric images and an antenna for implementation of the method.

So other international patents may be obtained at the selected countries.

Publications

The main publications of the method with system description and obtained results were published as:

• Shilo S.A., Sidorenko Yu.B. Millimeter wave imaging system // MSMW-07 Symposium proceedings, Kharkov, Ukraine, June 25-30, 2007. V.1, pp. 455-457.

• Shylo S., Sydorenko Yu., Wheeler D., Dundonald D. A W-band passive imaging system implemented with rotating diffraction antenna technology // Proc. of SPIE, Vol. 8900, pp. 890008-1 - 890008-10 (2013).

• Shylo S., Sydorenko Yu., Harmer S., Wheeler D., Dundonald D., Passive Millimetre-wave Imaging with a Planar Diffraction Antenna // CSNDSP14, 9-th IEEE/IET Int. Symposium on Communication Systems, Networks and Digital Signals Processing, 23-25 July 2014, Manchester Metropolitan University, pp. 1095-1099. ISBN 978-1-4799-2581-0

Sergiy Shylo, 2019
